Came DFWN2000 Resistive-mechanical safety strip 2m

CAME DFWN2000 Resistive-mechanical safety strip 2m

DFWN2000 is a resistive-mechanical safety strip that protects against damage or destruction of mechanical obstacles and gives active securing people. thanks to the appropriate profile shape and special patented internal CAME mechanism, is compatible with European ones standards.

DFWN is made of a very stable material (TPE 65 Short A), which makes it durable sensitive and flexible for a very long time and within a very wide range temperatures (-40/+80°C)

Features and Functions:

• Thanks to the sensitivity extended over its entire length, the strip protects against small and large obstacles
• Omni-directional obstacle detection
• Exceptional flexibility and durability
• Additional protection against impact and destruction

The edge strip is available upon individual order.

TECHNICAL DATA:

• Outputs: C-N.C. or C-N.O 3A/24V
• Length: 2m
• Maximum gate speed: 12m/min
• Protection level: IP54 (for vertical mounting)
• Insulation class: III
• Material: TPE 65Short A
• Operating temperature: -40°C / +80°C
